Sunday, July 22, 2018

Managing Complexity and Technical Debt : A Model for Quantifying Systemic Analysis





1. Introduction

Today’s post is a summer recreation/musing about how to model the effect of complexity and technical debt, in the same spirit of a the previous “Sustainable IT Budget in an equation” post. I used the word “recreation” to make it clear that this is proposed as “food for thoughts”, because I have worked hard to make the underlying model really simple, without the intent of accuracy. I have worked on IT cost modelling since 1998 and have removed layers of complexity and precision over the years to make this model a communication tool. You may see the result, for instance, in my lecture at Polytechnique about IT costs.

This post is a companion to the previous “Sustainable Information Systems and Technical Debt” with a few (simple) equations that may be used to explain the concepts of sustainable development  and complexity management to an audience who loves figures and quantified reasoning. It proposes a very crude model, that should be used to explain the systemic behavior of IT costs. It is not meant to be used for forecasting.
What is new in this model and in this post, is the introduction of change and the cumulated effect of complexity. The previous models looked at the dynamics of IT costs assuming an environment that was more or less constant, which is very far from the truth, especially in a digital world. Therefore, I have extended this simple model of IT costs into two directions:
  • I have introduced a concept of « decay » to represent the imperative for change. I am assuming that the value delivered by an IT system decreases over time following a classical law of “exponential decay”. This is a simple way to represent the need for « homeostasis », which is the need to keep in synch with the enterprise’s environment. The parameter for decay can be adjusted to represent the speed at which the external environment evolves.
  • I have also factored the effect of cumulated complexity into the model, as a first and simple attempt to model technical debt. This requires modelling the natural and incremental rise of complexity when IS evolves to adapt to its environment (cf. previous point) – as noticed before, there is a deep link between the rate of change and the importance of technical debt – as well as the representation of the effort to clean this technical debt.

This model makes use of Euclidean Scalar Complexity(ESC), a metric developed with Daniel Krob and Sylvain Perronet to assess integration complexity from enterprise architecture schema. ESC is easy to compute and is (more or less) independent from scale.  The technical contribution of this new model and blog post is to propose a link between ESC and technical debt. Although this link is somehow naïve, it supports “business case reasoning” (i.e., quantifying common sense) to show that managing technical debt has a positive long-term return on investment.

This post is organized as follows. Section 2 gives a short summary of asset management applied to information systems, in other words, how to manage information systems through replacement and renovation rates. This is the first systemic lesson: investments produce assets that accumulate and running costs follow this accumulation. The proposed consequence is to keep the growth and the age of the assets under control. Section 3 introduces the effect on computing (hardware) resource management on IT costs. We make a crude distinction between legacy systems where hardware is tied to application in a way that required a complete application re-engineering to benefit from better generations of computing resources, as opposed to modern virtualized architecture (such as cloud computing) that supports the constant and (almost) painless improvement of these resources. This section is a simplified application of the hosting cost model proposed in my second book, which yields similar results, namely that Moore’s law benefits only show in IT costs if the applicative architecture makes it possible. Section 4 introduces the need for change and the concept of exponential decay. It shows why managing IT today should be heavily focused on average application age, refresh rate and software asset inertia. It also provides quantitative support for concepts such as multi-modal Information Systems and Exponential Information Systems. Section 5 is more technical since we introduce Information System complexity and the management of technical debt from a quantified perspective. The main contribution is to propose a crude model about how complexity increases iteratively as the information system evolves and how this complexity may be constrained through refactoring efforts at the enterprise architecture level. Although this is a naïve model, at a macro scale, of technical debt, it supports quantified reasoning which is illustrated throughout this blog post with charts produced with a spreadsheet.

2. Asset Management and Information Systems


We will introduce the model step by step, starting with the simple foundation of asset management. At its simplest, an information system is a set of software assets that are maintained and renewed. The software process here is very straightforward: a software asset is acquired and integrated into the information systems. Then it generates value and costs: hosting costs for the required computing assets, support costs and licensing costs. The previously mentioned book gives much more details about the software assets TCO; this structure is also found in Volle  or Keen . The software lifecycle is made of acquisition, maintenance, renewal or kill.

Since the main object of the model is the set of software assets, the key metric is the size of this asset portfolio. In this example we use the Discounted Acquisition Costs model, that is the sum of the payments made for the software assets that are in use (that have not been killed) across the information system’s history.  The IS budget has a straightforward structure : we separate the build costs (related to the changes in the asset portfolio : acquisition, maintenance, etc.) and the run costs (hosting, support and licensing). Run costs are expressed directly as the product of resource units (i.e. the size of the IS / software assets) and unit costs (these unit costs are easy to find and to benchmark).

The model for the Build costs is more elaborate since it reflects the IS strategy and the software product lifecycle.  To keep things as simple as possible we postulate that the information system strategy in this model is described as an asset management policy, with the following (input) parameters to the model:
  • The total IT budget
  • The percentage of Build budget that is spent on acquiring new assets (N%)
  • The percentage of Build budget that is spent on retiring old assets (K%)
  • The percentage of Build budget that is spent on renewals (R%)

With these four parameters, the computation of each yearly iteration of the IT budget is straightforward. The run costs are first obtained from the IS size of the previous year. The build budget is the difference between total IT budget and run costs. This build budget is separated into four categories: acquiring new assets, killing existing (old) assets, replacing old assets with newer ones (we add to the model an efficiency factor which means that renewals are slightly more efficient than adding a brand-new piece of software) and “maintenance”. Maintenance (for functional or technical reasons) is known to produce incremental growth (more-or-less, it depends on the type of software development methodology) which we can also model with a parameter.

The model is, therefore, defined through two key equations which tells how the asset portfolio changes every year in size (S)  and age (A). Here is a simplified description (S’ is the new value of “assets size”, S is the value for the previous year):
  1. Growth of the assets:  S’ =  S -  Build x K% + Build x A% + Build x (1 – K% – A% – R%) x G%
  2. Ageing of the assets:  A’ = (A + 1) x (S – Build * (1 – N% - R% - K%)) / S’


Measuring software assets with Discounted Acquisition Costs has benefits and drawbacks. The obvious benefit is that it is applicable to almost all companies. The value that is used for discounting with age has a small effect on the overall simulation (and what will be said in the rest of the post). Typical values are between -3% to -10%. The drawback is that money is a poor measure of complexity and richness of the software assets. A better alternative is to use function points, but this requires a fair amount of efforts, over a long period of time. When I was CIO of Bouygues Telecom, I was a strong proponent of function points but I found it very hard to make sure that measurement was kept simple (at a macro scale) to avoid all the pitfalls of tedious and arguable accounting. What I have found over the years is that it is almost impossible to use function points without strong biases. However, as soon as you have a reasonable history, it works very well for year-by-year comparisons. Used at a macro scale, it also gives good benchmarking “orders of magnitudes”.  There are many other alternatives (counting apps, databases, UI screens, ….) that suffers from the same benefits and drawbacks. Since I aim to propose something generic here – and because discussing with CFOs is a critical goal of such a model -, using DAC makes the most sense.

The following chart gives an example of simulating the same information system, with the same constant budget, under three strategies:
  • The “standard strategy” is defined by N% = 5%, K% = 3%, R% = 50%. With 50% of the project budget spent on renewal, this is already a strong effort to keep the assets under control. The imbalance between what needs to be added (5% of the budget to meet new needs and a small effort for decommissioning) is quite typical.
  • The “clean strategy” is defined by N% = 5%, K% = 8%, R%=60%. Here we see the effect of try to clean up the legacy (more renewal effort, and more decommissioning).
  • The “careless” scenario is defined by N% = 5%, K% = 3% and R% = 30%. This is not a large change compared to the standard one, less effort is made on renewing assets so that more money can be spent on adapting the existing assets to the current needs.




These three figures illustrate some of the key lessons that have been explained before, so I will keep them short:
  • Changes that may seem small in the strategy (the values from the three scenarios are not all that different) produce significant differences over the years. Especially the “Build/Run” ratio changes significantly here according to the strategy that is picked.
  • Beware of accumulation, both in size and ageing, because once the problem accumulates it becomes hard to solve without a significant IT budget increase.
  • The effects of an aggressive cleanup asset management strategy are visible, and pay for themselves (i.e., they help free build money to seize new opportunities), but only after a significant period of time, because of the multiplicative effects. Therefore, there is no short-term business case for such a strategy (which is true for most asset management strategies, from real estates to wine cellars).

As I will explain in the conclusion, showing three examples does not do justice to the modelling effort. It is not meant to produce static trajectories, but rather to be played with in a “what if” game. Besides, there are many hypotheses that are specific to this example:
  • The ratio between the Build budget and the value of the asset portfolio is critical. This reflects the history of the company and differentiates between companies that have kept their software assets under control and those where the portfolio is too large compared to the yearly budget, because accumulation has already happened.
  • This example is built with a flat budget, but the difference gets bigger if there are budget constraints (additional project money is “free money” whereas “less project money” may translate to forced budget increase because renewing the SW assets is mandatory for regulatory reasons … or because of the competition).
  • The constants that I have used for unit costs are “plausible orders of magnitudes” gathered from previous instances of running such models with real data, but each company is different, and the numbers do change the overall story.
  • We do not have enough information here to discuss about the “business case” or the “return on investment” for the “cleanup strategy”. It really depends on the value that is generated by IT and the “refresh rate” constraints of the environment, which is what we will address in Section 4.


3. Managing Computing Infrastructures to Benefit Moore’s Law


In the previous model I have assumed that there is a constant (cf. the unit cost principle) cost of hosting a unit of software asset on computing resources. This is an oversimplification since hosting costs obviously depends on many factors such as quality of service, performance requirement and software complexity. However, when averaged over one or many data centers, these unit costs tend to be pretty “regular” and effective to forecast the evolution of hosting. There is one major difference that is worth modelling: the ability to change, or not, the computing & storage hardware without changing the software asset. As explained in my second book,  Moore’s Law only shows in IT costs if it is leveraged”, that is if you take advantage of the constant improvement of hosting costs. To keep with the spirit of a minimal model, we are going to distinguish two types of software:
  • Legacy: when the storage/computing configuration is linked to the application and is not usually changed until a renewal (cf. previous section) occurs. In this case, unit costs tend to show a slow decline over the years, due to automation and better maturity in operation, which is very small compared to the cost decrease of computing hardware. This was the most common case 20 years ago and is still quite frequent in most large companies.
  • Virtualized: when a “virtualization layer” (from VM, virtual storage to containers) allows a separation between software and computing assets. This is more common nowadays with cloud (public or private) architecture. Because it is easier to shift computing loads from one machine to another, hosting costs are declining more rapidly. This decline is much slower than Moore’s law because companies (or cloud providers) need to amortize their previous investments.


This split is easy to add into our asset model. It first requires to track software assets with two lines instead of one (legacy and virtualized), and to create two set of unit costs (which will reflect the faster reduction for virtualized hosting cost, as well as the current difference which is significant for most companies since virtualized load tend to run on “commodity hardware” whereas legacy software often runs on specialized and expensive hardware (the most obvious example being the mainframe).

The software asset lifecycles are coupled as follows. First the kill ratio K% must be supplemented with a new parameter that says how much of the effort is made on the legacy portfolio compared to the virtualized one. Second, we assume here – for simplification – that all applications that are renewed are ported to a newer architecture leveraging virtualized computing resources. Hence the renewal parameter (R%) will be the main driver to “modernize” the asset portfolio.

The following curves show the difference between three strategies, similarly to the previous section. We have taken a generic example where the portfolio is balanced at first between legacy and virtualized computing architecture. In this run, the new ratio (N%) is raised to 10% to reflect a situation where more change is required. The difference is mostly about the renewal rate (respectively 40%, 50% and 30%) and the kill rate (respectively 3%, 5% and 3%). The figure shows the size of the two software asset portfolios (Virtualized and Legacy) as well as the average age.



The model was run here with conservative costs estimates on purpose. The reader is encouraged to run this type of computation with the real values of unit cost that s/he may observe in her company. Even with this conservative setting, the differences are quite significant:
  • A sustained renewal effort translates into a more modern portfolio (the difference in average age is qui significant after 8 years) and lower run costs. It is easy to model the true benefits of switching to commodity hardware and leveraging virtualization.
  • The difference in the Build/Run ratio is quite high, because the run costs are much lower once a newer architecture is in place.
  • These efforts take time. Once again, the key “strategic agility” ration is “build/run”. When the asset portfolio has become too large, the “margin for action” is quite low (the share of the build budget that can be freely assigned to cleanup or renewal once the most urgent business needs have been served).


To make these simulations easier to read and to understand, we have picked a “flat IT budget scenario”. It is quite interesting to run simulations where the “amount of build project” has a minimal value that is bound to business necessities (regulation or competition – as is often the case in the telecom market). With these simulations, the worse strategy translates into a higher total IT cost, and the gap increases over the years because of the compounded effects.

4. Managing Information Systems Refresh Rate to Achieve Homeostasis


I should apologize for this section title which is a mouthful bordering on pretentious … however I have often used the concept of “homeostasis” in the context of digital transformation because it is quite relevant. Homeostasis refer to the effort of a complex systems (for instance a living organism) to maintain an equilibrium with its environment. In our world of constant changes pushed by technology rapid evolution, homeostasis refers to the constant change of the information system (including all digital assets and platforms) to adapt to the changing needs of customers and partners. From my own experience as an IT professional for the past 30 years, this is the main change that has occurred in the past decade: the “refresh rate” of information systems has increased dramatically. This is an idea that I have developed in many posts from this blog.

This is also a key idea from Salim Ismail’s best seller book “Exponential Organizations” which I have used to coin the expression “Exponential Information Systems”. From our IT cost model perspective, what this says is that there is another reason – other than reducing costs and optimizing TCO – to increase the refresh rate. I can see two reasons that we can to capture: first, the value provided by a software asset declines over time because the environment changes. Second, no software asset is isolated any more, each is part of a service (or micro service) orchestration patterns, that comes with its own refresh rate constraints. I have found that the best way to express both principles is to postulate that the value provided by a software asset declines over time following a classical exponential decay law:
                Value = V0 x exp(- lambda x time)

This formula is easy to introduce in our model, and it adds a penalty to ageing software that is independent from the previously mentioned TCO effects on licensing, maintenance, or hosting.  The decay parameter (lambda) is a way to tell the model that “software must change regularly” to cope with the constant changes of its environment.

I will not offer any simulation or charts here, because it is actually quite difficult to find data about this “decay” (need for change) and it makes little sense to invent one for a generic simulation. Also, not all software assets are equal with respect to exponential decay. Software-as-a-service (SaaS) is precisely an answer to this need for constant adaptation. Therefore, should we plan to run simulations seriously, we should use different decay constants for different classes of assets. There are plenty of software costs benchmarking materials that may be used to calibrate or evaluate the unit costs for the two previous models but evaluating the “rate of decay” is much more difficult and very specific to each industry.

On the other hand, exponential decay / forced rate of change is a really useful concept when planning about the long-term future of information systems. When one plays with the previous model augmented with decay, it becomes clear that the desired rate of change, which is a business imperative, is not compatible with the inertia that is exhibited by the model. This should be clear in the example shown in the previous section: the weight of the legacy portfolio is too high to obtain a homogeneous high refresh rate. In most large and established company, the Build/Run ratio is worse that what is proposed here, which means that the ability to increase the refresh rate is even worse.

This situation yields naturally to the concept of “multi-modal IT”, including the famous “bimodal IT” pattern.  A multi-modal information system is organized in an “onion structure” with a core and layers towards the periphery. Using API (Application Programming Interfaces), the onion may be organized so that the refresh rate is higher in the outside layers than in the core. This a direct application from biology and a pattern that is used in many organization theories such as betacodex. This is also the foundation for Exponential Information Systems: Use Enterprise Architecture and modularity to support different refresh rates for different parts of the information systems. The core/shared/pivot/common data model, that described the key business objects that are used throughout the multiple layers (multi-modal component) is a critical component of the Enterprise Architecture since it defines the agility through the API. A modular multimodal architecture is one that leaves most of the changes in the layers that were designed to accommodate high refresh rates. This means that modularity is a dynamic property of system architecture much more than a static one.

The lesson from this short section is that one should think really hard about the required refresh rates of sections of their information systems. For each functional domain, a target refresh rate (which is equivalent to a target average age for software assets) should be set. This target is both a business and technical imperative which should be based on requirements from customers and partners, as well as constraints related to software ecosystems. Many software environments, such as developing a mobile application, come with their own refresh rate constraints because the key features provided by the ecosystem change constantly … while upward compatibility is approximate at best. Similarly, the ambition to leverage artificial intelligence and machine learning for a given business domain should translate into setting a high refresh rate target. Keep in mind that adapting to the outside environment is a business imperative: if the lack of architecture modularity and the inertial of the accumulated weight of the asset portfolio prevent from upgrading the portfolio fast enough, the obvious solution is to grow this portfolio resulting in added complexity and IT costs.

5. Information Systems Complexity and Technical Debt


This last section introduces complexity and its effect on TCO in our IT cost model. We have seen throughout this post that the accumulation of weight is a burden, we shall now see that the accumulation of complexity is also a handicap that translates into additional costs, namely integration, testing and support costs. Obviously, the complexity of information systems reflects the complexity of their mission and the complexity of their environment. Somehow, this complexity is where part of the business value and differentiation is created. What we want to focus on here is the excess of complexity, which is precisely the definition of technical debt.

To introduce complexity in our model, we need a way to define and measure it. We shall use “Euclidean Scalar Complexity” because it is easy to understand and has a set of unique properties that makes it the best candidate for managing complexity at the Enterprise Architecture scale. The principle is quite simple. Assume that you have an architecture schema of your information systems, with boxes and links. Assume that you have a weight w(b) for each of the boxes, and that the existence of a link on your schema represents an interaction between the two subsystems represented by the box.  The weight could be the DAC measure of Section 2, the function points, or any additive metric that you like (i.e. w(a+b) = w(a) + w(b)). The Euclidean Scalar Complexity (ESC) of your architecture (abstraction of your system) is the square root of the sum of:  w(x) x w(y) for all pairs of boxes x, y that are either identical or joined with a link on the architecture schema. Normalized ESC means dividing the ESC value by the weight of the information systems, which yields a complexity ratio that we shall use in our model, a number between 0 and 1 (1 means that everything is connected and a value close to zero means that every piece is independent).

ESC is one of the few metrics that is “scale invariant”, which is the first requirement for working at the whole IS schema (each architecture schema is a crude abstraction) – see the 2007 paperComplexité des systèmes d’information: une famille de mesures de la complexité scalaire d’un schéma d’architecture” by  CASEAU Y., KROB D., PEYRONNET S. Being scale invariant means that if a change of scale is applied to the representation (more boxes and more links to represent the same information at a different scale), the complexity does not change. Another short introduction to ESC is provided in my Polytechnique lecture. There is no need to understand ESC in detail to see how it can be used to extend our IT cost model to manage technical debt, but the key insight that can help is to see that ESC is foremost a (static) modularity measure. ESC works well because it captures the benefits of Enterprise Architecture patterns such as gateways, integration buses, API encapsulation, etc. ESC is a great metric to capture the complexity of micro-service architectures.

As explained earlier, we do not suppose that the ideal information system has no complexity, but rather that for a given set of assets, there exists two complexity ratios, Cmin and Cmax, that represent on the one hand the minimal achievable ESC (i.e. rebuilding the IS from zero using the maximal possible modularity) and on the other hand, the complexity that one would get by randomly adding and integrating software assets incrementally. We used the normalized ESC, so these two numbers are between 0 and 1. Not all architecture problems are equal: some information systems are easy to build which translates into Cmin and Cmax being close. On the other hand, for many systems, the difference between Cmin, Cmax and C (the actual ESC ratio) is quite high. These two anchors makes possible the definition of technical debt as: w(S) x (C – Cmin) / (Cmax – Cmin)

Introducing technical debt into our cost model means two things:
  • Measuring the impact of this additional complexity on costs.
  • Defining and measuring what “reducing the technical debt” (i.e., managing complexity) may mean, in terms of effect and cost.

The first part is easy, considering the simplicity of our model and the fact we are just looking for simple orders of magnitude. In a same way that we have take the effect of aging into account for licensing, we upgrade the following formulas:
  • Integration costs are proportional to the ESC : for a project with no complexity at all it would be zero (negligible compared to the cost of building / buying the new component) whereas for a truly complex (C = 1.0) system, integration (and testing) costs are equal to the acquisition costs. This is very debatable (because it is so simple and because integration costs may be even worse) but it gives a first plausible value.
  • Support costs are also impacted: a fraction of support costs is proportional to C. This fraction is different for each information systems and depends on the nature of support activities (for instance, level 1 support is less impacted than level 3 support). Thus, this fraction is left as a model parameter.

The second part is the true extension of the model and what makes this post a new contribution to IT cost modelling.
  • Complexity without any refactoring effort evolves naturally towards Cmax as an asymptotic value (which is the definition of Cmax). The speed of evolution depends on how much of the information system is renewed each year, so the resulting complexity is a weighted average of the previous one and Cmax, where the weights are respectively the size of what is untouched in the portfolio and the size of what is added.
  • Refactoring is seen as a fraction of the renewal budget applied to reducing the complexity. The effect is described by a power law (declining return of the invested money). The maximal effect (the asymptotic value) is getting the complexity to Cmin (also by construction). I have used a power law with degree 4 which seems to reproduce the empiric observation that the refactoring efforts have a law of strongly diminishing returns (the last 60% benefits cost 80% of the effort).


The following illustration compares three IT strategies while taking technical debt into account. In this example we assume Cmin = 0.3 and Cmax = 0.6, with C = 0.5 at present time. The new parameters compared to section 1 are the amount of refactoring (F%) and how much of the kill effort is targeted towards legacy (small effect since the kill effort is small here).
  1. The “standard strategy” is defined by N% = 5%, K% = 3%, R% = 40% and F%=15%. Here 40% of the project budget is spent on renewal, and 15% of that money is reserved for refactoring. 70% of the kill effort is targeted towards legacy. The ESC ratio evolves from 0.5 to 0.489.
  2. The “intense strategy” is defined by N% = 5%, K% = 5%, R%=50% and F= 30% with 80% of kill effort put on legacy. This is a more sustained effort (since money applied to refactoring is not applied to adding new software assets). The complexity ration evolves from 0.5 to 0.464.
  3. The “careless” scenario is defined by N% = 5%, K% = 3% and R% = 30% and clean = 5%. These values are quite representative of most IT strategies (cf. what we said earlier, 30% of renewal is already the sign of a managed portfolio, many companies suffer from worse accumulation). Here the complexity moves from 0.5 to 0.509




These simulations are only proposed as an illustration. What can be learned through repeated simulations is similar to what we said in Section 2:
  • Efforts to clean up the portfolio, to keep the age and the complexity under control, are long-term efforts but they have lasting effects.
  • Accumulation in complexity, as well as accumulation in weight, has the dual effect of increasing the run costs and reducing the agility (the effort to change the information system to add new capacities becomes higher).
  • Contrary to section 2 and 3 where the models may be calibrated with well-known unit costs, measuring the negative effect of complexity and the positive effect of refactoring is hard. What is proposed here is a simple and conservative model that has the benefit of showcasing the effects of both but finding the right constant /parameters to match this model to your reality requires efforts and will lead to some “guesstimates”.
  • The key benefit of keeping weight and complexity under control is to allow for a higher refresh rate, which is itself a business imperative which can be modelled through “value decay” (Section 4). In order to simulate the value created by an aggressive “keep the complexity under control” strategy, you need to work under the situation of strong need for refresh (high decay). The weight of technical debt becomes a huge burden as soon as the environment requires to constantly update the information system.


6. Conclusion


The title for this blog post is: “Managing Complexity and Technical Debt: A Model for Quantifying Systemic Analysis”. There are two key ideas  here : the first one is “quantifying” and the second one is “systemic”. Both are related to the fact that this proposed model is foremost a communication tool. I decided to build a quantified model because this is the best way to communication with business managers. It does not mean that this model should be used for forecasting future IT costs, it is by far to simplistic. Using models and simulation is a great way to communicate with CFOs; they are even more effective if they rely on simple parameters/KPI such as unit costs that can be evaluated through benchmarking (cf. the Gartner paper on how CIOs can work with CFOs). To make this communication tool work for your case requires using your own data, as was said repeatedly.

The second benefit of working with a model is the benefit of simulation, which is a free benefit once you have built your own spreadsheet. Being able to play “what if” scenarios is critical to help your stakeholders understand the systemic nature of the IT costs:
  • Delays: good decisions may have long delays before showing their positive consequences
  • Accumulation: this is the main difficulty of managing information systems, once the cost problems are visible, they are much harder to solve.
  • Amplification (reinforcement): bad decisions produce waste that adds to the complexity and the overall weight, producing further problems along the way.


Although the topic is very different from the topics that I have covered using GTES (Game Theoretical Evolutionary Simulation), one can find the same pattern : a simple model is used to create simulations that are organized into a serious game from which systemic insights may be gained. As was stated earlier, the goal here is not to define the “best IT asset management strategy” using a crude model, but to gain a systemic understanding why long-term complexity-constrained asset management policies must be implemented.

Here are the conclusions that I can draw from playing with this generic model (more detailed conclusions would require working a on a specific instance):
  1. Keep the age of your software assets under control
  2. Keep the scope as small as possible (but not smaller, to paraphrase Einstein)
  3.  Constantly refactor your information systems, at different scales.










Monday, April 30, 2018

Artificial Intelligence Applications Ecosystem : How To Grow Reinforcing Loops ?




1. Introduction


Earlier this month the National Academy of Technologies of France (NATF) issued its report on the renewal of artificial intelligence and machine learning. This report is the work of the ICT (Information and Communication Technology) commission and may be seen as the follow-up of its previous report on Big Data. The  relatively short 100 pages document that was released builds on previous reports such as France IA report or the White House reports. It is the result of approximately 20 in-depth interviews (2 hours) with various experts from academy, software providers, startups and industry.

AI is a transforming technology that will find its way into most human activities. When writing this report, we tried to avoid what had been previously well covered in the earlier reports – which are summarized on pages 40-45 – and to focus on three questions:

  • What is Artificial Intelligence today?, from a practical perspective – from an AI user perspective. Although the “renewal” of interest in AI is clearly the consequence of the extraordinary progress of deep learning, there is more to AI than neural nets. There is also more to AI than the combination of symbolic and connectionism.
  • What recommendations could be made to companies who are urged everyday by news article to jump onto the “AI opportunity” – very often with too much hype about what is feasible today ? Many startups that we interviewed feared that the amount of hype would create disillusion (“we bring a breakthrough, but they expect magic”).
  • What could be proposed to public stakeholders to promote the French Artificial Intelligence Ecosystem, in the spirit of Emmanuel Macron’s discourse. Because of the diverse background of the NATF members, and because of our focus on technology, software and industrial applications, we have a large perspective of the AI ecosystem.


We never start to write a report without asking ourselves why yet another report would be needed. In the field of AI, Machine Learning or Big Data,  more reports have been written than a bookcase would hold. Our “innovation thesis” – what distinguishes our voice from others – can be roughly sumarized as follows:

  • The relative lag that we seen in France compared to other countries such as the USA when looking at AI applications is a demand problem, not a supply problem. France has enough scientists, startups and available software to surf the wave of AI and machine learning and leverage the powerful opportunities that have arisen from the spectacular progress in science, technology and practice since 2010.
  • Most successful applications of Artificial Intelligence and Machine Learning are designed as continuous learning and adaptive processes. Most often, success emerges from the continuous improvement that is fed by the iterative collection of feedback data. The “waterfall” cascade “business question -> specification of smart algorithm -> implementation -> execution” is something of the past century.
  • There is no successful AI application without software mastery. This is actually a consequence of the previous point as this blog post will make abundantly clear.
  • Similarly, AI success is most often drawn from future data more than past data. Too much emphasis has been put on “existing data as gold” while existing data in most company is often too sparse, to heterogenous, without the relevant meta-data (annotations). Data collection is a continuous active process, not something that is not once, to ensure that insights derived from AI are both relevant to the current world and constantly challenged by feedback.


This blog post is both intended as a short summary for English-speaking readers and a teaser for those who should read the full report. It is organized as follows. Part 2 describes the “tool box” of available AI techniques and attempts to give a sense of which are better suited to which types of problems. This part represents a large share of the full report, since we found after a few interviews that it was truly necessary to show what AI is from a practical viewpoint. Most existing successful industrial applications of AI today are not deep neural nets … while at the same time getting ready to leverage this “new” technology through massive data collection is urgently necessary. Part 3 details a few recommendations for companies who want to embark into their “AI journey”. From collecting the right amount of data, securing a large amount of computing power, ensuring a modern and open software environment to running teams in a “data science lab” mode, these recommendations are focused of favoring the “emergence” of AI success, rather than a top-down, failure-proof approach. The last part takes a larger perspective at the AI ecosystem and makes some suggestion about improving the health of our French AI applications. This last part is a follow-up to a number of brilliant posts about the “Villani report on AI” and the lack of systemic vision, such as Olivier Ezratty detailed and excellent review, Philippe Silberzhan criticism on the French obsession with “plans” and Nicolas Collin superb article about innovation ecosystems.



2. Taking a wide look at AI and ML



The following picture is borrowed from the report (page 52) and tries to separate five categories of  AI & ML techniques, sorted along two axes which represent two questions about the problem at hand:
  • Is the question narrowly and precisely defined – such as recognition of a pattern in a situation  - or is it more open-ended ?
  • Do we have lots of data available to illustrate the question – and to train the machine learning algorithm – or not ?


Sorting the different kinds of AI techniques along these two axes is an obvious simplification, but it helps to start. It also acts as a reminder that there is more than one kind of AI ... and that the benefits of Moore’s Law apply everywhere.








Let us walk quickly through each five categories:

  • The “agent / simulation” category contains methods that exploits the available massive computational power to run simulation of smart agents to explore complex problems. Sophisticated interaction issues may be explored through the framework of evolutionary game theory (for instance, GTES : Game-Theoretical Evolutionary Simulation). There exists a very large variety of approaches, which are well suited to the exploration of open questions and complex systems. COSMOTECH is a great illustration of this approach.
  • The “semantic category” is well illustrated by IBM Watson, although Watson is a hybrid AI system that leverages many techniques. The use of semantic networks, ontologies and knowledge management techniques has allowed “robot writers” to become slowly by surely better at their crafts, as illustrated by their use in few news articles. These techniques are well suited to explore very large amount of data with an open-ended question, such as “please, make me a summary”.
  • The middle category, which applicability spans over a large score, is made of “classical” machine learning and data mining algorithms, which are used today in most industrial applications (from predictive maintenance to fraud detection). This category is in itself a “toolbox” with many techniques that ranges from unsupervised clustering (very useful for exploration) to specific pattern recognition. Getting the best of this toolbox may be obtained through a “meta AI” that helps to select and parameterize the best algorithm or combination thereof. Einstein from Salesforce or TellMePlus are great illustration of these advanced “meta” AI techniques.
  • The fourth category is a combination of GOFAI (Good Old-Fashion AI), Rule-Based Systems, Constraint and generic problem solvers, theorem provers and techniques from Operations Research and Natural Language Processing. Here also, the toolbox is very large; putting these techniques into an AI landscape usually irritate scientists from neighboring domains, but the truth is that the frontiers are very porous. The interest of these approach is that they do not require a lots of training data, as long as the question is well defined. Although “expert system” sounds obsolete, many configuration and industrial monitoring systems are based on rules and symbolic logic.
  • The fifth category is deep learning, that is the use of neural nets with many layers to solve recognition problems. Deep neural nets are extremely good at complex pattern recognition problems such as speech recognition or machine vision. On the other had they require massive amount of qualified data to train. DNN are the de facto standard method today for perception problems, but their applicability is much larger (portfolio management, geology analysis, predictive maintenance, …) when the question is clear, and the data is available.


This is a somewhat naïve classification but is allows for a complete “bird view”. A more up-to-date, such as PWC list of Top 10 AI technology Trends for 2018, is necessary to better understand where the focus is today, but is usually more narrow and misses the contribution of other fields. A short description of deep neural nets (DNN) and convolution neural nets (CNN) is proposed in our report, but this is a fast moving field and recent online articles such as “Understanding Capsule networks” have an edge on written reports. There are still many open issues, that are recalled in the report, such as explicability (mostly for deep learning – which is one of the reason the other techniques are often preferred), the robustness of the trained algorithm outside its training set, the lack of “common sense” (a strength of human intelligence versus the machine) and the ability to learn from small data sets.

Even if deep neural nets may not deserve to be called a “revolution” considering that they have been around for a while, the spectacular progress seen since 2010 is a definitely a game changer. From AlphaGo and machine vision to automatic speech recognition, the reports recalls a few of the dramatic improvement that the combination of massive computing power, very large annotated data sets and algorithmic improvements have produced. This is “almost a revolution” for two reasons. First, although they require massive amount of training data and a precise question to work on (of the classification kind), DNN are very broad in their applicability. With the large availability of libraries such as TensorFlow, DNN has become a new, general purpose, tool in the tool box that may be applied to all types of applied business problems. Second, in a “system of systems” approach, DNN provide “perception” to smart systems, from machine vision to speech recognition, that may be used as input for other techniques. This is obviously useful when explainability is required. In a biomimetic way, DNN provides the low-level cognition methods (the recognition of low level patterns) while more classical methods ranging from rules to decision trees propose an explainable diagnosis. Similarly, semantic techniques and DNN for speech recognition work well together. It is clear that the “revolution” caused by the progress of DNN is in front of us, especially because machine vision will become ubiquitous with the combination of cheap cameras and neuromorphic chipsets.

The beauty of AI, and what makes it hard to understand from the outside, is the richness and complexity of techniques that allow the customization and combination of the techniques presented in the previous picture. There is an emerging consensus that the next generation of AI breakthroughs will come from the combination of various techniques. This is already the case today : many of the extraordinary systems, such as Watson, AlphaGo or Todai Robot, use a number of techniques and meta (hybridization) techniques. Here is a short overview to appreciate the richness of possible hybridization :

  • Reinforcement Learning has been around for a long time, it is one of the oldest technique from AI that is based on a continuous loop of incremental changes directed through a reward function. Libratus, the extraordinary AI poker player is based on the combination of smart reinforcement learning and non-connectionist machine learning.
  • Randomization (such as Monte-Carlo approach) and massive agents communities are borrowed from simulation methods to help explore large search space. They are often combined with “generation” methods, that are used to randomly explore parameterized sets of models, to produce additional data sets when not enough data is available, to explore meta-heuristic parameter sets (the smart “AI factories” such as Einstein or TellMePlus are examples of such approaches) or to increase the robustness such as the “Generative Adversarial Networks” example.
  • Evolutionary Game Theory brings game theoretical equilibriums such as Nash equilibrium into the iterative reinforcement loop (searching for the fixed point of what game theorists call the “best response”). Evolutionary game theory is great for simulating a smart group of actors that interact with each other (versus a unique single “smart” system).
  • Modular learning is based on the idea that some low-level behavior may be learned on one data set and transferred to another learning system. In the  world of neural nets, we speak of “transfer learning”. Modular learning is related of “systems of systems” architecture which is in itself a complex topic that will deserve a complete blog post. I refer as an example to the event-driven architecture proposed in this older post, which also related to biomimicry ( using not only the cortex, but the full cognitive/perception/emotion human system as an inspiration).


What is not covered in the report due to lack of time, is the “meta-meta level”, which is how the previous list of meta-techniques can be combined, as they often are in truly advanced systems. This shows that the first figure is naïve by construction and that practice really matters. Knowing the list of primitive techniques and algorithms is not enough to design a “smart” system that delivers value in a robust manner. There is no surprise there, most of these meta/combination methods have been around for a long time and used, for instance, in operations research application development.



3. Growing Continuous Learning Data Processing Flows


The first and main message that the report conveys to aspiring AI companies is to build their “training data set” strategy. There is nothing original here, this is the advice that comes from all kinds of experts (see the report), but there is more to it than it may sound.

  • The foundation of an AI strategy, as well as a digital strategy, is to collect, understand and distribute the data that is available to a company.  Collecting data into data lakes require a common shared business data model (data models are the corner stone of digital transformation, as well as collaborative and smart systems); collating data into training data sets require meta-data that captures business know-how as much as possible. I refer the reader to the “Mathematical Corporation” book that is full of great examples of companies that have started their AI journey with a data collection strategy.
  • Although it is not necessary to start experiment with deep learning at first (simpler methods often deliver great results and make for an easier first step in the learning curve), each company should become ready to leverage the transforming power of deep neural nets, especially in the machine vision field. As a consequence, one must get ready for collective massive data sets (millions to billions sample) and start to collect images and video in an industrial manner.
  • One must think about AI applications as processes that are built from data, meta-data, algorithms, meta-heuristics and training protocols in a continuous iterative improvement cycle. For most applications, data needs to be collected continuously, both to get fresh data that reflects the present environment (versus the pas) and to gather feedback data to evaluate the relevance of the training protocol. Autonomous robots are perfect examples of this continuous data flow acquisition and processing cycle.
  • The most critical expertise that companies will develop through time are the annotated data and the training protocols. This is where most of the business knowledge and expertise – hence the differentiation -  will crystallize. Algorithms will often be derived semi-automatically from the training sets (cf. the “data is the new code” motto from our previous report).



The second message of the report is that the time to act is now. As shown from the examples presented in “The Mathematical Corporation” or those found in our report, the “AI toolbox” of today is already effective to solve a very large number of business problems and to create new opportunities.

  • As stated in the introduction, Artificial Intelligence is a transforming technology. The journey of collecting, analyzing, and acting on massive amounts of business data tend to transform business processes and to produce new business insights and competitive IP.
  • AI is a practice, it takes time to grow. The good news is that AI expertise about your business domain is a differentiating advantage, the bad news is that it takes time and it is hard to catch up with your competitors if you get behind (because of the systemic effect of the loop that will be shown in the next section).
  • Computing power plays a critical role with the speed at which you may learn from data. In the past two years, we have collected a large evidence set of companies that have accelerated their learning by orders of magnitude when switching from regular servers to massive specialized resources such as GPU or TPU (ASIC).
  • Everything that is needed is already there. Most algorithms are easily available in open-source libraries. Many AI “workbench” solutions are available that facilitate the automatic selection of learning algorithms (to Einstein and TellMePlus we could add Holmes or Solidware, for instance).



The following picture – taken from a presentation at MEDEF last year -  illustrates the conditions that need to be developed to be “AI-ready”. In many companies, the right question is “what should we stop doing to prevent our teams from developing AI ?” versus “ what should we do/add/buy to develop our AI strategy ?”. This picture acts as “Maslow pyramid” : the foundation is the understanding that creating value from these approaches is an emergent process, that requires to “hedge one’s bets” and rely on empowered, distributed and autonomous teams. The second step is, as we just saw, to collect data and to grant access widely, modulo the privacy and IP constraints. The third step is to give the teams access with the relevant software environment: as up-to-date as possible, because algorithmic innovation is coming from the outside in a continuous flow, and with enough computing power to learn fast. Last these teams need to operate with a “data lab culture”, which is a combination of freedom and curiosity (because opportunities may be hidden from first sight) together with scientific rigor and skepticism. False positives, spurious correlation, non-robust classifiers … abound in the world of machine learning, especially when not enough data is available.





The third message that the reports addresses to companies is to think of AI in terms of flows (of enriched data) and (business) processes, not of technologies or value-added functions.

  • Although this is not a universal pattern, most advanced AI systems (from Amazon’s or Netflix’s recommendation engines to Criteo or Google AddSense add placement engines, through Facebook or Twitter content algorithms) are built through the continuous processing of huge flows of data as well as the continuous improvements of algorithms with millions of parameters. Distributed System Engineering and Large Data Flows Engineering are two critical skill domains to successfully bring AI to your company.
  • One must walk before running: there is a learning curve that applies to many dimensions. For instance, the path to complex algorithms must be taken step by step. First one play with simple libraries, then you associate with a local expert (university faculty member, for instance). Then you graduate to more complex solutions and you organize a Kaggle or local hackathon to look for fresh ideas. Once you have mastered these steps, you are in a better position to hire a senior expert at the international level, provided that your problem is worth it.
  •  “Universal AI” is not ready : AI for your specific domain is something that needs to be grown, not something that can be bought in a “ready for use” state. Which is why most of the experts that we interviewed were skeptics about the feasibility of “AI as a service” yet (with the exception of lower-level components such specific pattern recognition). Today’s (weak) AI is diversified to achieve the best results. The great “Machine Learning for Quantified Self” book is a good illustration: none of the techniques presented in this book are unique to Quantified Self, but the domain specificity (short time series) means that some classical techniques are better suited than others.

  • The numerous examples from the report or “The Mathematical Corporation” show that data collection must expand beyond the borders of the company, hence one must think as a “data exchange platform”.  This is another reason why software culture matters in AI : open data systems have their own ecosystems, mindsets and software culture.




4. How to Stimulate a Demand-Based Application Ecosystem



The following figure is taken from the press conference when we announced the report. It illustrates the concept of “multiple AI ecosystems” around the iterative process that we have just mentioned. The process is the backbone of the picture:  pick an algorithm, apply it to a data set to develop a “smart” system, deliver value/services from running this new system, develop its usage and collect the resulting data that will enrich the current data set (either to continuously enrich the dataset or to validate/calibrate/improve the precision/value of the current system), hence the loop qualified as “Iterative development of AI practice”. Each of the five steps comes with its own challenges, some of which are indicated on the figure with an attached bubble. Each step may be seen as an ecosystem with its players, its dominant platforms, its state-of-the-art practices and its competitive geography.






This figure, as well as a number of twin illustrations that may be found on Twitter, illustrates the competitive state of the French ecosystem:

  • The “upstream” science & algorithms part of the ecosystem is doing pretty well. French scientists are sought over, their open source contributions are well spread and recognized, and the French AI startups are numerous.
  • The “system engineering” step is less favorable to France since most major players are American (with the exception of China with its closed technology borders). Because of the massive advance of US in the digital world, practical expertise about large-scale distributed systems is more common in the US than in France. Trendsetting techniques in system engineering comes from the US, where they are better appreciated (cf. the success of Google’s “Site Reliability Engineering” book).
  • The “service ecosystem” reflects the strength of demand, that is the desire from CEOs and executive committees to leverage exponential technologies to transform their organization. I am borrowing the wording from “Exponential Organizations” on purpose: there is a clear difference in technology-saviness and risk-appetite across the Ocean, as recalled by most technology suppliers (large and small) that we interviewed.
  • The “service usage” ecosystem shows the disadvantage of Europe with its multiple languages and cultures compared to continent-states such as US or China. Trust is a major component of the willingness to try new digital services. We found that France is not really different from other European countries or even from the US but is lagging behind Asian countries such as South Korea or China.
  • Data collection is harder in Europe that elsewhere, mostly because of stricter regulation and heavier bureaucracy. It is fashionable to see GDPR as a chance for Europe but we believe that GDPR should be softened with application rules that support experimentation.
  • Last, although access to computing technology is ubiquitous, American companies tend to have a small edge as far as accessing large amounts of specialized resources is concerned.


One could argue with each of these assessments, finding them biased or harsh, but what matters is the systemic loop structure. To see where France will be compared to US or China five years from now, one must assess our ability to run the cycles many, many times for each “AI + X” domain. Hence a small disadvantage gets amplified many times (which is also why companies that started earlier and that have accumulated data and practice tend to learn faster than newcomers).

Stimulating the bottom-up growth of an emerging ecosystem is not easy, it is much more difficult than promoting a top-down strategic plan.  The report makes a few proposals, among which I would like to emphasize the following four:
  • Technical literature has been declining because of the Internet business model change, and this is especially keen for French technical press which is close to extinct. These communication channels used to play a key role for small innovative players to establish their credibility with regards to large corporate customers. Through hackathons, contests and challenges, technical evaluation, public spending and large-scale flagship projects, etc. public stakeholders must invest to help small but excellent technical players made their voices heard.
  • Stimulating the “pull”, i.e., the demand for AI and machine learning solution, is itself a difficult task but it is not impossible. The communication efforts of public stakeholders should focus more on successful applications as opposed to the fascinating successes of technology providers.
  • The NATF proposes to facilitate the setting up of Experimentation Centers associated to “IA + X” domains, through the creation of critical masses of data, talents, computing power and practices. An experimentation center would be a joint effort by different actors from the same business domain – in the spirit of an IRT – to build a platform where new algorithms could be tested against existing data sets and vice-versa.
  • Last, following the recommendation from the CGEIET report, the NATF strongly supports the certification of data analytics processes, where the emphasis is on end-to-end certification from collection to continuous usage and improvement. Au


It should be also said that one will find in the NATF report a summary of obviously relevant recommendations made in previous reports such as training or better support for research and science. I strongly recommend the UK report written by Wendy Hall and Jérôme Pesenti which addresses these topics very thoroughly.

5. Conclusion


The following is another “ecosystem schema” that I presented at the press conference earlier this month to position the NATF report with respect to the large crowd of reports and public figures’ opinions about Artificial Intelligence. The structure is the same as the previous cycle, but one may see that major ecosystems players have been spelled out. The short story is that the upstream ecosystem deserves some attention obviously but the numerous downstream ecosystems is where the battle should be fought, recognizing that France is really late for regaining domination in the software platform world.



To summarize, here is our contribution to the wonderful speech from the President Emmanuel Macron about Artificial Intelligence:
  • Don’t pick your battles too strongly in an emergent battlefield, promote and stimulate the large number of “AI+X” ecosystems. It is hard to guess where France will be better positioned 5 years from now.
  • Follow Francois Julien recommendations on how to effectively promote an emergent ecosystem: It is about growth (agriculture) more than selection (hunting). What is required is more stimulation than actions.
  • Focus on demand – how to encourage French companies to actively embrace the power of AI in their business activity – more than supply. Successful medium and large sizes AI companies will emerge in France if the local market exists.


In the same spirit, here is what the report says to companies:
  • Start collecting, sorting, enriching and thinking hard about your data,
  • “Let your teams work” from a mindset and a working environment perspective,
  • Think long-term, think “platform” and think about data flows.


Let me conclude with a disclaimer: the content of the report is a group effort that reflects as faithfully as possible the wisdom shared by the experts who were interviewed during the past 2 years. This blog summary is tinted by the author’s own experience with AI during the past 3 decades:
